Modular Aluminum Stage Truss for Events 500kg Capacity

  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
Lieu d'origine Jiangsu, Chine
Nom de marque Shizhan
Numéro de modèle Truss-rt en aluminium
Quantité de commande min 100
Prix $44-46

Contactez-moi pour des aperçus gratuits et des bons.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Si vous avez n'importe quel souci, nous fournissons l'aide en ligne de 24 heures.

x
Détails sur le produit
Type de connexion Connexion de PIN Capacité de chargement 500 kg
Matériel Alliage en aluminium Longueur de l'unité 0.5m, 1m, 2m, 3m, 4m, 5m ou adapté aux besoins du client
Forme de la ferme place, triangle, rond ou adapté aux besoins du client Forme de la section de treillis Carré ou Rond
Épaisseur du tube de la ferme 1,5 / 2/3 mm Diamètre du tube en treillis 20 mm, 32 mm, 50 mm
Dureté 16 degrés Ferme Pour les appareils à commande numérique
Fer à main moyen 290 * 290 mm, 300 * 300 mm; 350 * 350 mm, 300 * 400 mm; 400 * 400 mm; 450 * 450 mm; 400 * 600 mm roulement à roulements lourds 520 * 760 mm; 600 * 760 mm; 600 * 1000 mm
Épaisseur du tube principal 30 * 2 mm; 50 * 3 mm; 50 * 4 mm; 50 * 5 mm Épaisseur de tube de vice Pour les appareils à combustion électrique, la valeur de l'échantillon doit être égale ou supérieure
Épaisseur de tube Pour les appareils à commande numérique, les caractéristiques suivantes doivent être respectées:
Mettre en évidence

modular aluminum stage truss

,

aluminum lighting truss 500kg capacity

,

event truss with high load capacity
Laisser un message
Description de produit
Aluminium Stage Truss Structure Outdoor Stage Truss Design
Product Specifications
Attribute Value
Connection Type Pin Connection
Feature Durable
Frame design Modular
Product Type Display Truss
Application Events, Concert, Music, Performance, DJ Band, Event, Exhibition
Welding Welding
Load-bearing Capacity 500kg
Assembly Method Quick installation
Structure Type Modular Structure
Material Aluminum alloy
Unit length 0.5m, 1m, 2m, 3m, 4m, 5m or customized
Color Silver, black or customized
Truss section shape Square or round
Shape Square, Triangle, round or customized
Truss tube thickness 1.5/2/3MM
Truss tube diameter 20mm, 32mm, 50mm
Hardness 16 degree
Modular Aluminum Stage Truss for Events 500kg Capacity 0 Modular Aluminum Stage Truss for Events 500kg Capacity 1
Technical Details
Truss Material: Aluminum alloy 6082-T6
Light duty truss: 200*200mm; 250*250mm
Medium duty truss: 290*290mm, 300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm
Heavy duty truss: 520*760mm; 600*760mm; 600*1000mm
Main tube thickness: 30*2mm; 50*3mm; 50*4mm; 50*5mm
Vice tube thickness: 18*2mm; 20*2.5mm; 25*2.5mm
Brace tube thickness: 20*2mm; 25*2mm; 30*2mm
Length: 0.5m/1m/1.5m/2m...4m or custom size
Truss type: Spigot or bolt
Truss Shape: Ladder truss, triangular truss, square truss, arch truss, circle truss
Color: Silver or black, blue, green...
Usage: Concert, new product release, fashion show, booth stand construction
Delivery Time: 10 working days
Modular Aluminum Stage Truss for Events 500kg Capacity 2 Modular Aluminum Stage Truss for Events 500kg Capacity 3 Modular Aluminum Stage Truss for Events 500kg Capacity 4 Modular Aluminum Stage Truss for Events 500kg Capacity 5
Applications
Our aluminum alloy stage truss is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events and applications:
  • Concerts and festivals: Build stages for concerts, festivals, and outdoor events with configurable shapes and sizes
  • Theatrical productions: Construct sets, backdrops, and structures for plays, musicals, and operas
  • Exhibitions and trade shows: Create booths, displays, and exhibition structures
  • Corporate events: Build stages and backdrops for product launches, conferences, and award ceremonies
  • Sports events: Construct race start/finish lines, podiums, and scoreboards
Modular Aluminum Stage Truss for Events 500kg Capacity 6 Modular Aluminum Stage Truss for Events 500kg Capacity 7 Modular Aluminum Stage Truss for Events 500kg Capacity 8 Modular Aluminum Stage Truss for Events 500kg Capacity 9 Modular Aluminum Stage Truss for Events 500kg Capacity 10 Modular Aluminum Stage Truss for Events 500kg Capacity 11
Why Choose Our Products
  • TUV, SGS, CE Certified products
  • 15 years experience in truss, stage, barrier and scaffolding
  • 35,000 m² workshop with excellent production capacity
  • Professional engineering team for perfect project solutions
  • Own aluminum profile production line for quality control
  • Strict QC process with installation test before delivery
Frequently Asked Questions
How do I know your quality? Our products have TUV/SGS/CE/ISO9001 certificates and we offer samples for quality checking.
Payment methods: T/T, Western Union, Trade Assurance, L/C.
Warranty: 1 year warranty with free replacement for non-artificial damage.
Customization: Our technical team offers perfect solutions for custom projects.
Modular Aluminum Stage Truss for Events 500kg Capacity 12
