Aluminum Alloy Stage Truss for Concerts and Events
| Lieu d'origine | Jiangsu, Chine |
|---|---|
| Nom de marque | Shizhan |
| Numéro de modèle | Truss-rt en aluminium |
| Quantité de commande min | 100 |
| Prix | $52-55 |
Contactez-moi pour des aperçus gratuits et des bons.
whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
Si vous avez n'importe quel souci, nous fournissons l'aide en ligne de 24 heures.
xDétails sur le produit
| Type de connexion | Connexion de PIN | Forme | Rectangle, carré, triangle, rond ou personnalisé |
|---|---|---|---|
| Conception de cadre | Modulaire | Longueur | 10,0 à 4,0 m |
| Matériel | Alliage en aluminium | Capacité de chargement | 1000 kg |
| Longueur de l'unité | 0,5 m, 1 m, 2 m, 3 m, 4 m, 5 m ou personnalisé | Forme de la section de treillis | Carré ou Rond |
| Épaisseur du tube de la ferme | 1,5 / 2/3 mm | Diamètre du tube en treillis | 20 mm, 32 mm, 50 mm |
| Dureté | 16 degrés | Épaisseur du tube principal | 30 * 2 mm; 50 * 3 mm; 50 * 4 mm; 50 * 5 mm |
| Épaisseur de tube de vice | Pour les appareils à combustion électrique, la valeur de l'échantillon doit être égale ou supérieure | Épaisseur de tube | Pour les appareils à commande numérique, les caractéristiques suivantes doivent être respectées: |
| Type de botte | Spigot ou boulons | ||
| Mettre en évidence | aluminum alloy stage truss,concert lighting truss system,event truss with aluminum alloy |
||
Description de produit
Concert Stage Lighting Truss Aluminum
Product Specifications
| Connection Type | Pin Connection |
| Feature | Durable |
| Shape | Rectangle, square, Triangle, round or customized |
| Frame design | Modular |
| Product Type | Stage Truss |
| Application | Events, Concert, Music, Performance, DJ Band, Event, Exhibition |
| Length | 1.0-4.0m |
| Material | Aluminum Alloy 6082-T6 |
| Load-bearing Capacity | 1000kg |
| Assembly Method | Quick installation |
| Unit length | 0.5m,1m,2m,3m,4m,5m or customized |
| Color | Silver, black or customized |
| Truss section shape | Square or round |
| Truss tube thickness | 1.5/2/3MM |
| Truss tube diameter | 20mm,32mm,50mm |
| Hardness | 16 degree |
Detailed Specifications
| Light duty truss | 200*200mm; 250*250mm |
| Medium duty truss | 290*290mm,300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm |
| Heavy duty truss | 520*760mm; 600*760mm; 600*1000mm |
| Main tube thickness | 30*2mm; 50*3mm; 50*4mm; 50*5mm |
| Vice tube thickness | 18*2mm; 20*2.5mm; 25*2.5mm |
| Brace tube thickness | 20*2mm; 25*2mm; 30*2mm |
| Truss type | Spigot or bolt |
| Truss Shape | Ladder truss, triangular truss, square truss, arch truss, circle truss |
| Delivery Time | 10 working days |
Applications
Aluminum alloy stage truss is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events including:
- Concerts and festivals: For building stages with various configurations and accessories
- Theatrical productions: For constructing sets, backdrops, and stage structures
- Exhibitions and trade shows: For creating booths and display structures
- Corporate events: For product launches, conferences, and award ceremonies
- Sports events: For race start/finish lines, podiums, and scoreboards
This versatile solution offers durability, easy assembly, and customization options for various event requirements.
Frequently Asked Questions
Why should I choose your company instead of other suppliers?
- TUV, SGS, CE Certified products
- 15 years experience in truss and stage manufacturing
- 35,000 m² workshop with strong production capacity
- Professional engineering team for project solutions
- Own aluminum profile production line for quality control
- Strict QC process with installation testing before delivery
How do I know your quality? Do you support sample orders?
Our products have obtained TUV/SGS/CE/ISO9001 certificates. We can provide samples for quality evaluation before bulk orders.
Which payment methods do you accept?
T/T, Western Union, Trade Assurance, L/C.
What is your product warranty?
One year warranty covering any non-artificial damage with free replacement.
Can you do customized designs?
Yes, our technical team can provide perfect solutions for your specific project requirements.
